HP ProLiant DL380 Gen10 G10 2U Server 12x 3,5" LFF + 2x 2,5" SFF 2x Intel XEON Scalable LGA3647 DDR4 ECC Raid 2x PSU
without selected hdds or trays are no hdd trays included in delivery
information
2x FCLGA3647 Intel CPU Sockel für Skalierbare Intel® Xeon® Prozessoren - bis 28 Core CPU
24x DDR4 288pin ECC DIMM banks up to 3TB RAM
Intel® C621 Series Chipset
(Tertiary Riser not Configurable)
3x Riser interface:
Primary Riser CPU 1
Primary Riser 1 CPU 1:
1. PCIe 3.0 x8 - x8 Connector - Full-height,Full-length slot
2. PCIe 3.0 x8 - x16 Connector - Full-height,Full-length slot
3. PCIe 3.0 x8 - x8 Connector - Full-height,Half-length slot
Optional Secondary Riser CPU 2
Option Secondary Riser 1 CPU 2:
1. PCIe 3.0 x8 - x8 Connector - Full-height,Full-length slot
2. PCIe 3.0 x8 - x16 Connector - Full-height,Full-length slot
3. PCIe 3.0 x8 - x8 Connector - Full-height,Half-length slot
Option Secondary Riser 2 CPU 2:
1. -none-
2. PCIe 3.0 x16 - x16 Connector - Full-height,Full-length slot
3. PCIe 3.0 x16 - x16 Connector - Full-height,Half-length slot
Option Secondary Riser 3 CPU 2:
1. PCIe 3.0 x16 - x16 Connector - Full-height,Full-length slot
2. PCIe 3.0 x16 - x16 Connector - Full-height,Full-length slot
3. -none-
Integrated Storage Controller
S100i Storage Controller
Interfaces
3x SFF-8087 for up to 10x SATA
1x USB 3.0 connector
1x MicroSD card slot
1x FlexibleLOM slot
2x SATA
2x USB 3.0 (rear)
4x 1GbE LAN RJ-45 Copper
1x RJ-45 Servermanagement iLO 5 Port
1x VGA 15pol. D-SUB
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
(DE)
HP ProLiant DL380 Gen10
Konzipiert für anspruchsvolle Workloads bietet der HP ProLiant DL380 Gen10 2U Server herausragende Leistung und Flexibilität.
Mit bis zu zwei Intel Xeon Scalable Prozessoren im Dual-Betrieb und DDR4 ECC RAM ausgestattet, sorgt er für schnelle Datenverarbeitung und hohe Datensicherheit. Die 12x 3,5'' LFF- und 2x 2,5'' SFF-Laufwerksschächte ermöglichen vielseitige Speicherlösungen, während die integrierte RAID-Unterstützung maximale Datenverfügbarkeit gewährleistet.
Duale Netzteile (PSU) bieten ausfallsicheren Betrieb - ideal für Virtualisierung und hybride Cloud-Umgebungen.
(EN)
HP ProLiant DL380 Gen10
Designed for demanding workloads, this server combines outstanding performance and flexibility.
Powered by up to two Intel Xeon Scalable processors in a dual-socket and DDR4 ECC RAM, it ensures fast data processing and robust data security.
With 12x 3.5" LFF and 2x 2.5" SFF drive bays, it offers versatile storage options, supported by integrated RAID for maximum data availability. Dual power supplies (PSU) ensure reliable, uninterrupted operation, making the HP ProLiant DL380 Gen10 2U Server ideal for virtualization and hybrid cloud environments.
