HP ProLiant DL385 Gen10 Plus V2 2U Server 8x 2,5" SFF SAS SATA 2x AMD EPYC Gen2 Gen3 DDR4 ECC Raid 2x PSU
Product description
Vendor: HP
Unit type: Server
Type: 19" 2 HE
Model: ProLiant DL385 Gen10Plus V2
HDD bays: 8x HotSwap HDD Bays SAS/S-ATA Backplane
without selected hdds or trays are no hdd trays included in delivery
without selected hdds or trays are no hdd trays included in delivery
Optical drive: ohne
Networking: optional selectable
Internal interfaces:
2x AMD EPYC SP3 CPU Sockel für 2. und 3, Generation 7002 7003 EPYC CPU bis zu 64 Core per CPU
No chipset – System on Chip (SoC) design
32x DDR4 288pin ECC DIMM banks up to 4TB RAM - 8 channel per CPU
3x Riser interface:
Primary Riser CPU 1
Option Primary Riser 1 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x16 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector- Full-height,half-length slot
Option Primary Riser 2 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Primary Riser 3 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Secondary Riser CPU 2
Option Secondary Riser 1 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x16 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Secondary Riser 2 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Secondary Riser 3 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector- Full-height,half-length slot
Tertiary Riser CPU 2
Option Tertiary Riser 1 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Tertiary Riser 2 CPU 2:
1. PCIe 4.0 x8 - x8 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x8 Connector - Full-height,full-length slot
maximal mit Primary, Secondary sowie Tertiary Riser, 8x Full Profile PCIe Interfaces möglich
1x SFF-8087 S-ATA
1x SFF-8654 S-ATA
1x OCP 3.0 module Slot
1x USB 3.0 connector
1x MicroSD card slot
2x SATA Onboard
2x AMD EPYC SP3 CPU Sockel für 2. und 3, Generation 7002 7003 EPYC CPU bis zu 64 Core per CPU
No chipset – System on Chip (SoC) design
32x DDR4 288pin ECC DIMM banks up to 4TB RAM - 8 channel per CPU
3x Riser interface:
Primary Riser CPU 1
Option Primary Riser 1 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x16 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector- Full-height,half-length slot
Option Primary Riser 2 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Primary Riser 3 CPU 1
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Secondary Riser CPU 2
Option Secondary Riser 1 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x16 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Secondary Riser 2 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Secondary Riser 3 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
3. PCIe 4.0 x8 - x16 Connector- Full-height,half-length slot
Tertiary Riser CPU 2
Option Tertiary Riser 1 CPU 2:
1. PCIe 4.0 x8 - x16 Connector - Full-height,full-length slot
Option Tertiary Riser 2 CPU 2:
1. PCIe 4.0 x8 - x8 Connector - Full-height,full-length slot
2. PCIe 4.0 x8 - x8 Connector - Full-height,full-length slot
maximal mit Primary, Secondary sowie Tertiary Riser, 8x Full Profile PCIe Interfaces möglich
1x SFF-8087 S-ATA
1x SFF-8654 S-ATA
1x OCP 3.0 module Slot
1x USB 3.0 connector
1x MicroSD card slot
2x SATA Onboard
External interfaces:
3x USB 3.0 (1x front)
1x optional OCP 3.0 Port to add different network controllers
1x RJ-45 Servermanagement iLO5 Port
1x VGA 15pol. D-SUB
1x iLO Front Service Port (Optional)
3x USB 3.0 (1x front)
1x optional OCP 3.0 Port to add different network controllers
1x RJ-45 Servermanagement iLO5 Port
1x VGA 15pol. D-SUB
1x iLO Front Service Port (Optional)
Videocard: onboard
Powerunits: 2x HP HotSwap Power supply (800W or 1600W)
Net weight: 14 kg
Installation depth: 73 cm
Dimensions: L: 74,3 cm | B: 48,3 cm | H: 8,8 cm
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux systems: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux systems: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Item condition: refurbished, Grade A
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
manufacturer information:
enterprise.kunden@hpe.com
HP Deutschland
Herrenberger Straße 140
71034 Böblingen
Deutschland
Product No.: SK0504
Base price: 2.121,00 €
incl.
19% MwSt | excl. Shipping
Price excl. VAT: 1.782,35 €
Availability:
Shipping time: 2-5 days + shipping time (excl. weekend, excl. business holidays)
Weight KG: 26.00kg
