Lenovo IBM SR950 19" 4U 8x 2,5" SFF SAS NVMe 8x Intel XEON Scalable Gold Platinum LGA3647 96x DDR4 ECC Raid 4x PSU -CTO-
Product description
Vendor: Lenovo
Unit type: Server
Type: 19" 4 HE
Model: ThinkSystem SR950
HDD bays: 8x HotSwap HDD Bays SAS/S-ATA 12Gb/6Gb Backplane
without selected hdds or trays are no hdd trays included in delivery
without selected hdds or trays are no hdd trays included in delivery
RAM: DDR4 registered ECC (PC4-2400T default memory speed with RAM selection)
Optical drive: ohne
Networking: none - optional LOM card
Internal interfaces:
Intel C624 Chipsatz
8x CPU Sockel FCLGA3647 Intel Xeon Scalable processors with max. 205W
96x DDR4 DIMM slots up to 24TB RAM
PCIe Slots:
2x PCIe 3.0 x16 Full Profile, Half-Length
2x PCIe 3.0 x16 Low Profile, Half-Length
1x PCIe 3.0 x8 Low Profile, Half-Length
2x PCIe for RAID Controller
1x PCIe 3.0 x16 ML2, low profile
1x PCIe 3.0 x8 LOM adapter slot
Intel C624 Chipsatz
8x CPU Sockel FCLGA3647 Intel Xeon Scalable processors with max. 205W
96x DDR4 DIMM slots up to 24TB RAM
PCIe Slots:
2x PCIe 3.0 x16 Full Profile, Half-Length
2x PCIe 3.0 x16 Low Profile, Half-Length
1x PCIe 3.0 x8 Low Profile, Half-Length
2x PCIe for RAID Controller
1x PCIe 3.0 x16 ML2, low profile
1x PCIe 3.0 x8 LOM adapter slot
External interfaces:
Front: Two USB 2.0 ports (one also for XCC local management), and one VGA video port
Rear: Two USB 3.0, one VGA video, one DB-9 serial, and one 1 GbE RJ-45 systems management. The serial port can be shared with the XCC for serial redirection functions. Only one VGA port can be used at a time.
Front: Two USB 2.0 ports (one also for XCC local management), and one VGA video port
Rear: Two USB 3.0, one VGA video, one DB-9 serial, and one 1 GbE RJ-45 systems management. The serial port can be shared with the XCC for serial redirection functions. Only one VGA port can be used at a time.
Videocard: onboard
Powerunits: up to 4x Lenovo HotSwap Power supply
Net weight: 42,91 kg
Installation depth: 80,5 cm
Dimensions: L: 85 cm | B: 48,5 cm | H: 17,5 cm
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Item condition: refurbished, Grade A
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
Der Lenovo IBM SR950 4U Server setzt neue Maßstäbe für extreme Leistung und Skalierbarkeit in Rechenzentren
Mit Unterstützung für bis zu 8x Intel Xeon Scalable Gold oder Platinum Prozessoren und unglaublichen 96x DDR4 ECC RAM-Steckplätzen, bietet dieser Server unvergleichliche Rechenleistung und Flexibilität.
Ideal für High-Performance-Computing und Virtualisierung, verfügt er über 8x 2,5'' SFF SAS/NVMe-Laufwerksschächte und vier Netzteile für höchste Ausfallsicherheit.
Perfekt für Unternehmen, die maximale Effizienz und Skalierbarkeit benötigen.
Product No.: SK0531
Base price: 1.621,00 €
incl.
19% MwSt | excl. Shipping
Price excl. VAT: 1.362,18 €
Availability:
Shipping time: 2-5 days + shipping time (excl. weekend, excl. business holidays)
Weight KG: 42.91kg
