Supermicro CSE-829U X11DPU 19" 2U 12x 3,5" LFF 4x NVMe U.2 2x Intel XEON Scalable DDR4 ECC Raid 2x 10GbE X540-T2 2x PSU
Product description
Vendor: Supermicro
Unit type: Server
Type: 19" 2 HE
Model: CSE 829U X11DPU
HDD bays: 12x HotSwap HDD Bays SAS/S-ATA Backplane
without selected hdds or trays are no hdd trays included in delivery
without selected hdds or trays are no hdd trays included in delivery
RAM: DDR4 registered ECC (PC4-2400T default memory speed with RAM selection)
Optical drive: ohne
Networking: 2x 10GbE RJ-45 Cooper AOC-2UR68-I2XT
Internal interfaces:
2x Intel Xeon Scalable Gen1 Gen2 Processor LGA-3647 (Socket P) supported, CPU TDP support up to 205W TDP, 2 UPI up to 10.4 GT/s
24x DDR4 288pin ECC DIMM Banks up to 6 TB RAM
Intel C621 chipset
Integrated IPMI 2.0 and KVM with Dedicated LAN
2x SuperDOM (Disk on Module) port with build power
1x PCI-E 3.0 x16 slot (FH, 10.5" L)
5x PCI-E 3.0 x8 slots (FH, 10.5" L) (4x x8 optional replaceable with 2x x16)
1x PCI-E 3.0 x8 slot (LP)
1x PCI-E 3.0 x8 slot (internal LP)
4x PCIe 3.0 NVMe x4 Internal Port(s)
14x SATA3 (6Gbps); RAID 0, 1, 5, 10
3x USB 3.0 (2 rear, 1 Type A)
1x TPM Header & Chip both
12x 3,5" LFF HDD HotSwap Bays 12G SAS 6G S-ATA / SAS3 Backplane BPN-SAS3-826EL1-N4
2x Intel Xeon Scalable Gen1 Gen2 Processor LGA-3647 (Socket P) supported, CPU TDP support up to 205W TDP, 2 UPI up to 10.4 GT/s
24x DDR4 288pin ECC DIMM Banks up to 6 TB RAM
Intel C621 chipset
Integrated IPMI 2.0 and KVM with Dedicated LAN
2x SuperDOM (Disk on Module) port with build power
1x PCI-E 3.0 x16 slot (FH, 10.5" L)
5x PCI-E 3.0 x8 slots (FH, 10.5" L) (4x x8 optional replaceable with 2x x16)
1x PCI-E 3.0 x8 slot (LP)
1x PCI-E 3.0 x8 slot (internal LP)
4x PCIe 3.0 NVMe x4 Internal Port(s)
14x SATA3 (6Gbps); RAID 0, 1, 5, 10
3x USB 3.0 (2 rear, 1 Type A)
1x TPM Header & Chip both
12x 3,5" LFF HDD HotSwap Bays 12G SAS 6G S-ATA / SAS3 Backplane BPN-SAS3-826EL1-N4
External interfaces:
3x USB 3.2 Gen1 port(s) (2 via header; 1 type A)
2x USB 3.0 port(s) (2 rear)
2x 10GbE Intel X540-T2 onto SuperRiser
1x RJ45 Dedicated IPMI LAN port
2x VGA 15pol. D-SUB
1x Seriell RS232 interface
3x USB 3.2 Gen1 port(s) (2 via header; 1 type A)
2x USB 3.0 port(s) (2 rear)
2x 10GbE Intel X540-T2 onto SuperRiser
1x RJ45 Dedicated IPMI LAN port
2x VGA 15pol. D-SUB
1x Seriell RS232 interface
Videocard: onboard Aspeed AST2500 BMC
Powerunits: 2x 1000W HotSwap Power Supply
Net weight: 13,4 kg
Installation depth: 75 cm
Dimensions: L: 79 cm | B: 48,4 cm | H: 9 cm
Compatible operating systems:
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Windows: Windows Server 2016, 2019, 2022*; Windows 10, 11*
*compatible TPM module is required
Virtualisierung: vmware ; Citrix ; Microsoft Hyper-V ; Proxmoxx; Linux KVM
Linux Betriebssysteme: Linux Suse, Linux RHEL (RedHat), Debian, Fedora etc.
Item condition: refurbished, Grade A
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
Every device has been cleaned and carefully checked before delivery. Latest free available firmware has been flashed on systembios, storage-, network- and management controller.
manufacturer information:
Support_Europe@Supermicro.com
Super Micro Computer, Inc.
Het Sterrenbeeld 28
5215 ML, s-Hertogenbosch
Niederlande
Super Micro Computer, Inc.
980 Rock Avenue
San Jose, CA 95131
USA
Product No.: SK0411
Base price: 692,00 €
incl.
19% MwSt | excl. Shipping
Price excl. VAT: 581,51 €
Availability:
Shipping time: 2-5 days + shipping time (excl. weekend, excl. business holidays)
Weight KG: 26.00kg
